ATI tv wonder elite?! (1 Viewer)

[cl2yp71c]

MediaPortal Version: 0.2.0.0
Windows Version: SP2
CPU Type: Intel dual-core 2.8ghz
HDD: Intel 320gb
Memory: 1gb ddr2
Video Card: GeForce 7900 GS
1. TV Card: ATI TV Wonder Elite
TV - HTPC Connection: Composite

Hi, my tv tuner card works normally with MCE while on media portal this is what I get:

any suggestions?
thx



[CHli]

Do you have the last driver installed ?

ATI TV Wonder Elite is the Theater 550 based one ?

Thanks



[cl2yp71c]

I have the latest driver which i got from the ATI site https://support.ati.com/ics/support/default.asp?deptID=894&task=knowledge&folderID=27

and yes, I i believe it is theater based



[SciDoctor]

These are the filters required

ATI AVStream Analog Tuner" checkdevice="true"/>
<filter cat="tvaudio" name="ATI AVStream Analog TV Audio" checkdevice="true"/>
<filter cat="crossbar" name="ATI AVStream Analog Xbar" checkdevice="true"/>
<filter cat="capture" name="ATI AVStream Analog Capture" checkdevice="true"/>
<filter cat="mux" name="ATI AVStream MPEG2 Multiplexer" checkdevice="true"/>
</filters>

Download graphedit and check that these filters exist .

The latest filter for the 'ATI AVStream Analog Capture' from ATI has changed and they have dropped a pin output so this makes the MP filter graph construct not work as the pins are reasigned incorrectly.

Load this filter into graphedit and list the ouput pins from right side; top to bottom and i can then see if the filter construct can be changed for you.



[cl2yp71c]

I am sorry for my nubiness but what exactly am I supposed to do?



[audball]

MediaPortal Version: 0.2.0 RC4
Windows Version: XP sp 2
CPU Type: AMD 64 3200
HDD: 160 GB Raid 0
Memory: corsair PC3500
Motherboard: DFI RS480
Motherboard Chipset: ATI
Motherboard Bios:
Video Card: ATI X300
Video Card Driver:
Sound Card:
Sound Card AC3:
Sound Card Driver:
1. TV Card: ATI 550 Pro
1. TV Card Type: PCI EXPRESS
1. TV Card Driver: LATEST
2. TV Card:
2. TV Card Type:
2. TV Card Driver:
3. TV Card:
3. TV Card Type:
3. TV Card Driver:
4. TV Card:
4. TV Card Type:
4. TV Card Driver:
MPEG2 Video Codec: Intervideo
MPEG2 Audio Codec: Intervideo
Satelite/CableTV Provider: Cable
HTPC Case:
Cooling:
Power Supply:
Remote:
TV:
TV - HTPC Connection:


I'm having same problem
Graphedit shows all filters required are installed.
Not sure if this card being PCI express matters.



[SciDoctor]

From your attached picture the filtrers and pin in-outs match the graph construct.

Check the dev-id from within graphedit for the filter

ATI AVStream Analog Capture

and see if this matches any of the these

devid="ven_1002&amp;dev_4d53&amp;subsys_a3471002&amp;rev_00"

devid="ven_1002&amp;dev_4d52&amp;subsys_a3451002&amp;rev_00"

devid="ven_1002&amp;dev_4d53&amp;subsys_a3481002&amp;rev_00"

devid="ven_1002&amp;dev_4d52&amp;subsys_a3461002&amp;rev_00"



[audball]

Well not exactly
Look at attached file



[audball]

Also my card has no FM tuner
You can go here to see what it looks like

http://www.pcalchemy.com/product_in...uners?osCsid=0a5e792f06199692dfb48268c8c86e90



[SciDoctor]

devid="ven_1002&amp;dev_4d53&amp;subsys_a5031028&a mp;rev_00"

Use the above in place of the one in the graph construct for your card in the config xml file.
