HE-AAC support (DVB-T)

Discussion in 'Improvement Suggestions' started by ganger_rolf, November 13, 2007.

  1. ganger_rolf
    • Premium Supporter

    ganger_rolf MP Donator

    Joined:
    January 14, 2007
    Messages:
    10
    Likes Received:
    0
    Ratings:
    +0 / 0
    Home Country:
    Norway Norway
    Show System Specs
    Started on: 2007-11-13
    last update: 2008-01-08

    Summary: Norwegian television (NTV) started their DTT-service this autumn based on mpeg4 (h.264/he-aac). NTV is among the first to broadcast DVB-T audio in he-aac (aac high efficiency), and until now no there has been no software solution for viewing DTT live in Norway with sound. FireDTV launched a beta version of their viewer 2007-11-09 that support these he-aac streams.



    Description: Enable Mediaportal/TV-server to read he-aac (latm) in ts-streams.
    As far as I know, at least this needs to be done (based on the work done in DVBviewer):

    1. Create a AAC-pin in the TS-filter used in Mediaportal/TV-server

    2. Create a window in Mediaportal/Options where you can choose a dedicated AAC-decoder (in addition to the existing "audio decoder"-window)

  2. Google AdSense Guest Advertisement



    to hide all adverts.
  3. knutinh

    knutinh Portal Pro

    Joined:
    September 4, 2005
    Messages:
    558
    Likes Received:
    2
    Ratings:
    +2 / 0
    Something is finally happening.

    Background:
    The Norwegian DVB-T network is using h264 and HE-AAC with LOAS/LATM. Almost the entire rest of the world use MPEG2.

    For those having a terratec tuner, the accompanying beta-version of terratec software is reported to work for non-encrypted channels (NRK1,2 and 3)
    ftp://ftp.terratec.de/Receiver/TerraTec_HomeCinema/Beta/

    DVBViewer is reported to support HE-AAC (for any hardware) "soon":
    http://www.dvbviewer.com/en/index.php?page=news&article=Version 3.9.0 released

    The situation for encrypted channels is what? FireDTV?


    It seems strange that this took so long, and that solutions are so bound to hardware. I thought that the idea behind DirectShow was that applications could handle any media as long as the appropriate filter existed, and the filters used by terratec could be reused by mediaportal if they are regular DS filters, right?

    -k

  4. Darre

    Darre Portal Pro

    Joined:
    April 21, 2007
    Messages:
    925
    Likes Received:
    80
    Ratings:
    +80 / 0
    Home Country:
    Norway Norway
    Still no way to watch the encrypted channels as RiksTV wont approve of any CAM. They are "working" on it.

  5. slarve

    slarve Portal Member

    Joined:
    July 30, 2007
    Messages:
    11
    Likes Received:
    0
    Ratings:
    +0 / 0
  6. Spragleknas
    • Team MediaPortal
    • Administrator

    Spragleknas Administrator

    Joined:
    December 21, 2005
    Messages:
    9,472
    Likes Received:
    1,385
    Gender:
    Male
    Occupation:
    Occupied
    Location:
    Located
    Ratings:
    +1,892 / 12
    Home Country:
    Norway Norway
    Show System Specs
    Welcome to the forums, slarve, and thanks for informative post!

    Also, with TerraTec Piranha ( <- probably misspelled) audio is working. Soon on all TerraTec products. This is done by a DirectShow-filter from what I read, so it should be possible to get it to work with MP. (Perhaps after fiddling with graphedit)

    EDIT: OK, I have registered the above mentioned AAC LATM decoder (Direct Show). If anybody knows of any stream-dumps I'll see if it works in Mediaportal (don't have a DVB-T card).

  7. slarve

    slarve Portal Member

    Joined:
    July 30, 2007
    Messages:
    11
    Likes Received:
    0
    Ratings:
    +0 / 0
  8. ganger_rolf
    • Premium Supporter

    ganger_rolf MP Donator

    Joined:
    January 14, 2007
    Messages:
    10
    Likes Received:
    0
    Ratings:
    +0 / 0
    Home Country:
    Norway Norway
    Show System Specs
  9. mcraenz
    • Premium Supporter

    mcraenz MP Donator

    Joined:
    July 28, 2007
    Messages:
    647
    Likes Received:
    44
    Location:
    Auckland
    Ratings:
    +47 / 0
    Home Country:
    New Zealand New Zealand
    Show System Specs
    Yeah it looks like we're in the same boat down here in New Zealand. Our trials have been running about 2 months now.

    I have uploaded a sample raw .ts file of a DVB-T HD h.264 AAC MUX to ftp.team-mediaportal.com NZ_MediaWorks_570_T_TV3_FTA.ts


    When I try to view a channel on this mux I just get a single frozen frame. If I try to record I get a 0kb .ts file. What are you guys experiencing?

    Cheers,
    mcraenz

  10. dman_lfc
    • Premium Supporter

    dman_lfc Retired Team Member

    Joined:
    July 28, 2004
    Messages:
    1,772
    Likes Received:
    30
    Occupation:
    Sales Manager
    Location:
    UK
    Ratings:
    +30 / 0
    Home Country:
    New Zealand New Zealand
    Working on it guys.
    TVServer will now recognize the channels correctly and record the LATM AAC audio streams.
    Problem is parsing the audio through TSReader at the moment.

    You can play the TVServer .TS recordings through the latest SVN release of VLC so at least thats something.

    DMAN

  11. mcraenz
    • Premium Supporter

    mcraenz MP Donator

    Joined:
    July 28, 2007
    Messages:
    647
    Likes Received:
    44
    Location:
    Auckland
    Ratings:
    +47 / 0
    Home Country:
    New Zealand New Zealand
    Show System Specs
    Yep can confirm recording working here :D

    New Zeeland :D you DMAN


    Attached Files:

    • nz.jpg
      File size:
      74.3 KB
      Uploaded:
      February 25, 2008
      Views:
      247
