TV-Server Version:
MediaPortal Version:
MediaPortal Skin:
Windows Version:
CPU Type: EC6600
HDD: 500GB Seagate
Memory: 4GB
Motherboard:ASUS P5B
Motherboard Chipset: 725
Motherboard Bios:
Video Card: 8800GT
Video Card Driver:
Sound Card: On Board
Sound Card AC3: ??
Sound Card Driver:
1. TV Card: MSI TV@nywhere A/D 1.1
1. TV Card Type:
1. TV Card Driver:
2. TV Card:
2. TV Card Type:
2. TV Card Driver:
3. TV Card:
3. TV Card Type:
3. TV Card Driver:
4. TV Card:
4. TV Card Type:
4. TV Card Driver:
MPEG2 Video Codec:
MPEG2 Audio Codec:
Satelite/CableTV Provider:
HTPC Case:
Cooling:
Power Supply:
Remote:
TV:
TV - HTPC Connection:
I have installed the Card, configured it in the MP configuration app. It found the card, scan the stations, everything OK.
When i go into MP and select TV it shows nothing and then crashes if i try to do anything, like change the channel.
I have add what i think is correct configuration after going through the graphedit process...although to be honest it didn't mean muich to me. Added the results to the bottom of the xml file:
Here's my GraphEdit if that helps.
MediaPortal Version:
MediaPortal Skin:
Windows Version:
CPU Type: EC6600
HDD: 500GB Seagate
Memory: 4GB
Motherboard:ASUS P5B
Motherboard Chipset: 725
Motherboard Bios:
Video Card: 8800GT
Video Card Driver:
Sound Card: On Board
Sound Card AC3: ??
Sound Card Driver:
1. TV Card: MSI TV@nywhere A/D 1.1
1. TV Card Type:
1. TV Card Driver:
2. TV Card:
2. TV Card Type:
2. TV Card Driver:
3. TV Card:
3. TV Card Type:
3. TV Card Driver:
4. TV Card:
4. TV Card Type:
4. TV Card Driver:
MPEG2 Video Codec:
MPEG2 Audio Codec:
Satelite/CableTV Provider:
HTPC Case:
Cooling:
Power Supply:
Remote:
TV:
TV - HTPC Connection:
I have installed the Card, configured it in the MP configuration app. It found the card, scan the stations, everything OK.
When i go into MP and select TV it shows nothing and then crashes if i try to do anything, like change the channel.
I have add what i think is correct configuration after going through the graphedit process...although to be honest it didn't mean muich to me. Added the results to the bottom of the xml file:
PLEASE help me...I am an idiot!<capturecard commercialname="TV@nywhere A/D" capturename="713X BDA Digital Capture" devid="ven_1131&dev_7133&subsys_86251462&rev_d1">
<capabilities tv="true" radio="true" mpeg2="true" mce="true" sw="true" bda="true"></capabilities>
<tv>
<interface cat="capture" video="2" audio="3" mpeg2="1" sectionsandtables="5"></interface>
<filters>
<filter cat="networkprovider" name="Microsoft DVBT Network Provider" checkdevice="false"></filter>
<filter cat="tunerdevice" name="713X BDA DVBT Tuner" checkdevice="false"></filter>
<filter cat="capture" name="713x BDA Digital Capture" checkdevice="false"></filter>
</filters>
<connections>
<connection sourcefilter="networkprovider" sourcepin="0" sinkfilter="tunerdevice" sinkpin="0"></connection>
<connection sourcefilter="tunerdevice" sourcepin="0" sinkfilter="capture" sinkpin="0"></connection>
</connections>
</tv>
</capturecard>
Here's my GraphEdit if that helps.
