    Well I decided to get a new HTPC case I saw this on ebay and had to get it I love the clean look to it.

    First I had to remove everything from the old case and get it all ready to go in the new case.

    Then I took replaced the cpu cooler with this Silverstone one
    Newegg.com - SILVERSTONE NT07-AM2 80mm CPU Cooler - CPU Fans & Heatsinks

    I replaced the fan it came with to a Silenx fan
    The two case fans were already Silenx fans when I got it
    Then I replaced the 120mm fan in the psu to a Silenx



    I had to find a good way to mount the hdd since I use a 2.5" IDE and my dvd burner
    is also IDE and there was no slot under the dvd drive for a hdd so I had to improvise
    since the IDE cable wont reach over to the hdd bays which I removed anyways.

    I hooked the hdd to the bottom of the dvd drive mount with a zip tie and put some foam
    inbetween just so nothing vibrated



    I had a usb IR receiver and I wanted to mount it in the case and since this case
    is made to take a OLED screen in the front it had a piece of clear plastic already
    in it, so I took my usb receiver and poped the cover off and mounted it in the case
    right behind the window




    Then of course I had to neaten up all the wires so it looked nice



    System specs are

    Omaura TF8 case
    Biostar 7050PV/nForce 630a AM2 mobo
    AMD 4850e 45w cpu
    Leadtek 8500GT Silent Edition Low Profile HDMI
    4 GB DDR2 800 ram ( it was cheap)
    120GB Samsung 2.5" hdd
    Lite-on dvd burner
    Sunbeam Hush 550W psu

    Here are some pics of the front and back




    ryan20021982

    Retired Team Member
  • Premium Supporter
  • June 27, 2008
    655
    86
    USA
    Home Country
    United States of America United States of America
    Got it for right around $150 shipped but there hard to find , the company went under awhile back


    pilehave

    Community Skin Designer
  • Premium Supporter
  • April 2, 2008
    2,566
    521
    Hornslet
    Home Country
    Denmark Denmark
    Too bad the OLED never got to work under MediaPortal, I would have bought one of those cases myself if it worked, but now it's all in the past. Let's hope that better displays comes around - I'm already tired of my 2x16 VFD :rolleyes:


    karu

    Portal Member
    November 28, 2007
    16
    0
    Home Country
    United States of America United States of America
    i'm so upset, that dell stopped selling these. I bought like every accessory, got the case, but then i get an e-mail that they are no longer selling omauras...so the remote, LCD, was a no go. and no other US seller has them >.< i want to cry


    wolfi_b

    MP Donator
  • Premium Supporter
  • April 10, 2008
    799
    38
    Home Country
    Austria Austria
    I had a usb IR receiver and I wanted to mount it in the case and since this case
    is made to take a OLED screen in the front it had a piece of clear plastic already
    in it, so I took my usb receiver and poped the cover off and mounted it in the case
    right behind the window

    wich one is this?


    ryan20021982

    Retired Team Member
  • Premium Supporter
  • June 27, 2008
    655
    86
    USA
    Home Country
    United States of America United States of America
    I had a usb IR receiver and I wanted to mount it in the case and since this case
    is made to take a OLED screen in the front it had a piece of clear plastic already
    in it, so I took my usb receiver and poped the cover off and mounted it in the case
    right behind the window

    wich one is this?

    Its actually one that came with a Aver Media tv tuner I had but it was in a little case
    and I took it out of the case, could do the same with any usb ir receiver.
