DTS Passthrough Stutter (1 Viewer)

[booba5185]

MediaPortal Version: 1.2.1
MediaPortal Skin: STreamedMP
Windows Version: XP
CPU Type: Q9400
HDD: lots
Memory: 4gb ddr2\800
Motherboard: EP45-UD3P
Video Card: GTS-250
Video Card Driver: Nvidia
Sound Card: Asus Xonar DX
Sound Card AC3:
Sound Card Driver:
1. TV Card:
1. TV Card Type:
1. TV Card Driver:
2. TV Card:
2. TV Card Type:
2. TV Card Driver:
3. TV Card:
3. TV Card Type:
3. TV Card Driver:
4. TV Card:
4. TV Card Type:
4. TV Card Driver:
MPEG2 Video Codec:
MPEG2 Audio Codec:
h.264 Video Codec:
Satelite/CableTV Provider:
HTPC Case:
Cooling:
Power Supply:
Remote:
TV:
TV - HTPC Connection:
Hey everyone, I'm having a very hard time finding out whats causing this stutter with DTS passthrough. I've tried all the codec combinations I can think of. Currently I have SAF 6 with ffdshow DXVA, with ffdshow audio decoder running. I've tried Spdifer, Ac3filter, LAV, and obviously ffshow. If passthrough is enabled, I get a stutter. CPU utilization is under 25% the entire time, plenty of rm available, etc. If passthrough is disabled, then it works fine. I had passthrough working just great, but I had to reformat and ever since then I can't get it to work. Any ideas?



[1stdead]

Please post screenshot from graphedit when playing stuff and from audiosettings.
Graphedit is a part of SAF, you'll find it in tools. Pull the movie over in graphedit.



[booba5185]

Here's a screenshot of graphedit, which audio settings did you want a screenshot of?



[1stdead]

Ac3filter as you're using it


Edit: however i would be better to uninstall everything and use SAF. the lavfsplitter, audio decoder etc. is the way to go from now.



[booba5185]

Here's AC3filter, funny thing is that when I'm in Mediaportal, ffdshow is used; at least the icon is on the taskbar while the movie is playing.

here's ffdshow:

I don't think that MP is using ac3filter, because it is set to passthrough, which is not happening at all. If I set it to passthrough in ffdshow, it will passthrough, with the stuttering of course.



[1stdead]

Ok, then instead play a movie in MP and then swap out of it, Alt+tab and open graphedit > file > connect to remote graph and show us which codecs are used when you play in mediaportal.


Well you don't have passthough enabled in ffdshow.



[booba5185]

In order for a movie to play (withoutstutter) I have to have passthrough disabled. I'll enable it for this screenshot though.

this was when passthrough was enabled through ffdshow.



[1stdead]

Ok.. Shouldn't happen. I remember having same issue, but not how i fixed it.(perhaps you have a bad svn version?)

The easiest solution would now be to uninstall every codec you have and then install SAF6 https://forum.team-mediaportal.com/codecs-331/saf-v6-00-based-lavf-95635/
Please set settings acording to the screenshots and during install tick use passthrough. Should be more or less obvious how to do it.


Let me know what happens then.



[booba5185]

I have tried that numerous times, but I will try it one more time just to be sure.



[1stdead]

Yeah, well something is wrong with your merits. And SAF does not use ffdshow nor AC3filter for passthrough any more.
